Extron Debuts Convection-Cooled Rackmount Amps
Extron's 1U amps are convection-cooled for use in low-ventillation environments. |
Extron Electronics has launched four new models in its XTRA series of 1U convection-cooled amplifiers, including two- and four-channel models, as well as two models supporting 70 volt speakers.
The new rackmount two-channel and four-channel amplifiers, dubbed the XPA 2002 and XPA 2004, respectively, offer a power of 200 watts per channel with an impedance of 4 ohms (Ω) or 100 watts per channel with an impedence of 8 Ω.
The two models that support 70 volt speakers include the XPA 2002-70V, a unit offering two channels with 200 watts per channel, and the XPA 2003C-70V, an amp that comes equipped with one channel featuring 200 watts and two channels producing 200 watts per channel at 4 Ω of impedance.
All of the new amps feature a fanless convection cooling system that uses side-mounted heat sinks, allowing the units to be used in low-ventilation environments. Thermal dissipation for the units is 30 watts at idle for the XPA 2002-70V and XPA 2004, 23 watts for the XPA 2002, and 18 watts at idle for the XPA 2003C-70V. (Standby is less than 1 watt for all of the units.)
The models also offer a low inrush current, allowing the amps to be set up without power sequencing, and power factor correction, a technology that reduces high-frequency harmonics.
Other features include:
- Ripple suppression technology for a cleaner audio waveform;
- 27 dB gain;
- A frequency response of 20 Hz to 20 kHz;
- An automatic clip limiter;
- Auto power down; and
- Protection circuits for DC faults and thermal overloads.
All models in the XTRA series are designed to meet Energy Star 2.0 qualifications and include a three-year parts and labor warranty. Further information is available here.
About the Author
Dan Thompson is a freelance writer based in Brea, CA. He can be reached here.
